Add a touch probe to access difficult-to-image or otherwise inaccessible features, to more fully characterize parts in a single setup. The SmartScope Flash 302 is one of the most versatile benchtop systems QVI offers.
SMARTSCOPE FLASH 300 FULL
MVP features full field-of-view image processing with advanced edge detection algorithms designed for repeatability in real-world applications. SmartScope MVP features a joystick-controlled precision mechanical bearing XYZ stage, with 0.5 m (X and Y axes) and 1.0 յm (Z axis) linear glass scales mounted on a metrologically stable granite base and column. Surface and back lighting in conjunction with a high-resolution color camera provide high contrast, true-color images. Optional screw-on lens attachments expand the magnification range ٖ a low cost way to increase system versatility. A precise 6.5 to 1 automatic zoom lens with ample 80 mm working distance keeps images in focus and on-axis throughout the zoom range. Automated SmartScope MVP systems are equipped with servo-driven motorized stages, and use OGPΒs powerful and intuitive Measure-X > metrology software, for completely automated inspection and/or measurement. While the instrument head moves in the X, Y and Z axes, the part being measured remains stationary.SmartScope MVP metrology system is a cost-effective way to get the benefits of automated video-based inspection and measurement from the leading name in the industry Ζ Optical Gaging Products (OGP company). Its unique carbon fiber composite X-axis beam exhibits superior noise-dampening characteristics, while its light weight contributes to measurement speed. SmartScope® Flash™ 635 (635 x 635 x 200 mm) – Provides measurement speed and stability. This design assures rapid, smooth part translation and robust measurement performance. An extended Y-axis travel of 610 mm is optional and either 300 mm or 400 mm extended Z-axis travel is available. OGPs SmartScope CNC range generates multi-sensor measurements, maintaining the highest. Parts move on a precision DC motor-driven Y-axis stage while the optics assembly travels in the X-axis across a stable bridge cross member. SmartScope® Flash™ 500 (Contact us for XYZ Stage Travel details) – Offers all the great Flash features and performance in a large, travel bridge-design system. It also comes standard with a TTL coaxial illuminator and patented LED SmartRing™ light. A high-quality auto calibrating AccuCentric® 12:1 zoom lens provides excellent optical performance over its entire range. OGP SMARTSCOPE SPECIALIST 300 See more models of this Type See more models for this Brand. It contains a unique “elevating bridge” design and axial straightness and perpendicularity are built in to meet stringent volumetric specifications. Add optional through-the-lens (TTL) laser, touch probe or micro-probe to configure a highly capable multisensor system. With an expansive Z-axis of 250 mm (10 in.) to accommodate large parts, it combines state-of-the-art video and autofocus to deliver high productivity. SmartScope® Flash™ 302 (300 x 300 x 250 mm) – One of the most versatile benchtop systems OGP offers. It’s ideal for a wide variety of manufacturing industries including metalworking, plastics, biomedical, electronics, automotive, aerospace and more.
SMARTSCOPE FLASH 300 SOFTWARE
Its heavy cast base and rigid steel column provide metrology integrity so accuracy can be maintained in real world environments. Like all Flash systems, it is equipped with OGP® Measure-X® metrology software and 12:1 AccuCentric® zoom optics. Its large 300 mm X travel makes it the system of choice for measuring critical dimensions of long parts on a benchtop machine. SmartScope® Flash™ 250 (300 x 150 x 200 mm) – A compact machine designed for easy access to the XY stage for maximum fixturing flexibility. SmartRing™ light is standard for the ultimate flexibility in surface illumination. The computer controlled LED array backlight tracks X-axis motion of the optics with no moving parts. It also has patented innovations that let users do more, faster. Innovative design features of “elevating bridge” and an embedded computer mean the system takes up little space on a benchtop while providing an ample measuring range and extensive measurement capabilities. SmartScope® Flash™ 200 (200 x 200 x 150 mm) – The smallest member of the Flash family of systems is a full-featured automatic measurement system.
